Layer control
Export cut, bend, and marking geometry with dedicated production rules.
Product details
Batch DXF Export from SOLIDWORKS Assemblies
Flat2DXF Standard and Professional reduce repetitive SOLIDWORKS exports by generating DXF files for multiple sheet metal parts in one controlled workflow.
Native C# add-inSOLIDWORKS 2018-2025Windows x64Offline license
Flat2DXFSOLIDWORKS
SOLIDWORKS is a trademark of Dassault Systemes SolidWorks Corporation or its affiliates. Flat2DXF is an independent product and is not affiliated with, endorsed by, sponsored by, approved by, certified by, or an official product of Dassault Systemes or SOLIDWORKS.
Product details
Organized output package
Flat2DXF groups geometry and documentation into one handoff structure so CAD/CAM teams can review layers, bend lines, and reports faster.
Batch export
Turn sheet metal parts in an assembly into production files without opening each part.
Reporting
Organize shop-floor handoff with part summaries, drawings, and package outputs.
Workflow
Four steps inside SOLIDWORKS
Download the Windows installer from your account.
Open a sheet metal part or assembly inside SOLIDWORKS.
Configure layers, bend lines, naming, and report options.
Generate DXF, PDF, production report, and ZIP output.
Try it with your own SOLIDWORKS files
Create an account, download the installer, and test the Flat2DXF workflow with your own shop files.
FAQ
Product questions
Why use batch DXF export?
It saves time when many sheet metal parts need DXF files for fabrication or quoting.
Can output names be automated?
Yes. Flat2DXF supports automated naming and structured export packages.
Can reports be included?
Yes. Standard includes PDF material lists and Professional adds technical PDF outputs.
